$7,000
Condition
excellent
Year
2018
Make
Kubota
Model
BX23S
Fuel Type
Diesel
Transmission
Hydrostatic
Condition:
excellent
Drive Type:
MFWD
Transmission:
Hydrostatic
Engine Size:
0.9L
Cylinders:
3
Condition:
excellent
Engine Size:
0.9L
Condition:
excellent
Description
General Information
Year: 2018
Make: Kubota
Model: BX23S
Serial Number: 24810
Drive Type: MFWD
Transmission: Hydrostatic
Hours: 177
Horsepower: 22 HP
Fuel Type: Diesel
PTO: Independent Rear – 540 RPM
Mid-Mount PTO: Yes
3-Point Hitch: Category 1
Loader: Yes
Make: Kubota
Model: LA340
Bucket: 4 ft quick-attach front bucket
Backhoe: Yes
Make: Kubota
Model: BT603
Bucket: 1 ft digging bucket
Tire Type: Turf tires – Singles
Front: 18x8.50-10
Rear: 26x12.00-12
Wheel Type: Tires
ROPS: Foldable
Condition: Excellent
Engine Details
Engine Make: Kubota
Engine Model: D902
Engine Type: 3-Cylinder, Liquid-Cooled Diesel
Displacement: 0.898 L (54.8 cu. in.)
Horsepower: 22 HP gross @ 3,200 RPM
Rated RPM: 3,200
Air Intake: Dry-type dual element
Fuel System: Indirect injection
Cooling System: Water-cooled radiator
Fuel Tank Capacity: 6.6 gallons (25 L)
Starting System: Electric – 12V
Features & Equipment
Transmission & Drivetrain
Type: 2-Range Hydrostatic Transmission
Control: Twin pedal foot control
Drive…
General Information
Year: 2018
Make: Kubota
Model: BX23S
Serial Number: 24810
Drive Type: MFWD
Transmission: Hydrostatic
Hours: 177
Horsepower: 22 HP
Fuel Type: Diesel
PTO: Independent Rear – 540 RPM
Mid-Mount PTO: Yes
3-Point Hitch: Category 1
Loader: Yes
Make: Kubota
Model: LA340
Bucket: 4 ft quick-attach front bucket
Backhoe: Yes
Make: Kubota
Model: BT603
Bucket: 1 ft digging bucket
Tire Type: Turf tires – Singles
Front: 18×8.50-10
Rear: 26×12.00-12
Wheel Type: Tires
ROPS: Foldable
Condition: Excellent
Engine Details
Engine Make: Kubota
Engine Model: D902
Engine Type: 3-Cylinder, Liquid-Cooled Diesel
Displacement: 0.898 L (54.8 cu. in.)
Horsepower: 22 HP gross @ 3,200 RPM
Rated RPM: 3,200
Air Intake: Dry-type dual element
Fuel System: Indirect injection
Cooling System: Water-cooled radiator
Fuel Tank Capacity: 6.6 gallons (25 L)
Starting System: Electric – 12V
Features & Equipment
Transmission & Drivetrain
Type: 2-Range Hydrostatic Transmission
Control: Twin pedal foot control
Drive Mode: Selectable 4WD
Brakes: Wet disc brakes, left-side pedal
Steering: Hydrostatic power steering
Hydraulics & PTO
Hydraulic System: Open center
Hydraulic Flow: 6.2 GPM
Implement Pump Flow: 3.6 GPM
Power Steering Pump Flow: 2.6 GPM
Rear PTO: 540 RPM
Mid PTO: 2,500 RPM
3-Point Hitch: Category 1, limited
Lift Capacity at 24” behind lift point: 680 lbs
Loader
Type: Quick-attach
Lift Capacity to Full Height at Pivot Pin: 739 lbs
Max Lift Height: 71 in
Bucket Width: 48 in
Control: Joystick mounted to right fender
Backhoe
Digging Depth: 6 ft
Reach from Swing Pivot: 8.7 ft
Bucket Digging Force: 2,200 lbs
Boom Swing Arc: 140°
Seat: Swivel seat from operator to backhoe position
Operator Station
ROPS: Foldable
Seat: High-back, suspension seat with armrests
Instrumentation: Analog gauges for RPM, fuel, temp
Controls: Ergonomic side lever placement
Lighting: Front headlights and work lights
Dimensions & Weight
Overall Length with Backhoe: ~95 in
Width: 45.1 in
Height: 86 in
Wheelbase: 55.1 in
Ground Clearance: 8.4 in
Weight: ~2,600 lbs
Buy with Confidence: we are so confident in the condition of our item that we offer a 10-day inspection policy and a 6-month warranty!
– Clean Title!
– Excellent Condition!
– Backed by our 6-month warranty!
– 10-Day Inspection Policy!
We also offer nationwide shipping at a competitive rate of $0.80 per mile. Our shipping service is handled with the utmost care, ensuring that your item arrives safely and in the same excellent condition in which it leaves our lot.
Whether you’re local or across the country, we’re committed to delivering the best online-buying experience possible. Reach out today and let us help you find your next item!
Contact us today for more information!!
