$13,800
Condition
excellent
Year
2021
Make
Kubota
Model
SVL97-2
Fuel Type
Diesel
Transmission
Hydrostatic
Condition:
excellent
Drive Type:
CTL
Transmission:
Hydrostatic
Engine Size:
3.8L
Cylinders:
4
Condition:
excellent
Engine Size:
3.8L
Condition:
excellent
Description
General Information
Year: 2021
Make: Kubota
Model: SVL97-2
Type: Compact Track Loader
Hours: 601
Drive Type: Track – Rubber
Transmission: 2-Speed Hydrostatic
ROPS Type: Cab
Condition: Excellent
Operator Station: Enclosed Cab with Heat, A/C, and Radio
Engine Details
Engine Make: Kubota
Engine Model: V3800-TIF4
Engine Type: 3.8L, 4-Cylinder, Turbocharged, Diesel
Displacement: 3.769 Liters (230 cu in)
Gross Horsepower: 96.4 HP
Net Horsepower: 92 HP @ 2400 RPM
Torque: 280 ft-lbs
Fuel Type: Diesel
Emissions Compliance: Tier 4 Final – DOC + DPF + SCR
Cooling System: Liquid-cooled
Fuel Tank Capacity: 28 gallons
Starting System: Electric, 12V
Features
Transmission & Drivetrain
Drive System: 2-Speed Hydrostatic
Travel Speeds:
Low: 5.0 mph
High: 7.8 mph
Traction Control: Standard
Final Drive: Planetary-type
Track Type: Rubber, 17.7 in (450 mm)
Undercarriage: Sealed & Lubricated Rollers, Triple Flange
Ground Clearance: 11.5 in
Track Tension: Grease-adjustable
Hydraulics
Hydraulic System Type: Closed-center, Load-sensing
Main Pump Flow: 23.9 GPM
High Flow: 40.0…
General Information
Year: 2021
Make: Kubota
Model: SVL97-2
Type: Compact Track Loader
Hours: 601
Drive Type: Track – Rubber
Transmission: 2-Speed Hydrostatic
ROPS Type: Cab
Condition: Excellent
Operator Station: Enclosed Cab with Heat, A/C, and Radio
Engine Details
Engine Make: Kubota
Engine Model: V3800-TIF4
Engine Type: 3.8L, 4-Cylinder, Turbocharged, Diesel
Displacement: 3.769 Liters (230 cu in)
Gross Horsepower: 96.4 HP
Net Horsepower: 92 HP @ 2400 RPM
Torque: 280 ft-lbs
Fuel Type: Diesel
Emissions Compliance: Tier 4 Final – DOC + DPF + SCR
Cooling System: Liquid-cooled
Fuel Tank Capacity: 28 gallons
Starting System: Electric, 12V
Features
Transmission & Drivetrain
Drive System: 2-Speed Hydrostatic
Travel Speeds:
Low: 5.0 mph
High: 7.8 mph
Traction Control: Standard
Final Drive: Planetary-type
Track Type: Rubber, 17.7 in (450 mm)
Undercarriage: Sealed & Lubricated Rollers, Triple Flange
Ground Clearance: 11.5 in
Track Tension: Grease-adjustable
Hydraulics
Hydraulic System Type: Closed-center, Load-sensing
Main Pump Flow: 23.9 GPM
High Flow: 40.0 GPM
Auxiliary Hydraulic Pressure: 3,553 psi
Standard Auxiliary Hydraulics: Yes – Front Mounted
Coupler Type: Flat-face quick couplers
Hydraulic Cooling Fan: Variable speed, temperature controlled
Lift & Loader Specs
Lift Type: Vertical Lift
Rated Operating Capacity: 3,200 lbs
Tipping Load: 9,143 lbs
Breakout Force: 7,961 lbs
Breakout Force: 7,034 lbs
Lift Height to Hinge Pin: 128.7 in
Bucket Compatibility: Standard ISO Quick-Attach
Cab & Comfort
Fully Enclosed ROPS/FOPS Cab
Factory-Installed HVAC
Suspension Seat with Armrests
Radio with Bluetooth/AM/FM
Digital Display with Machine Diagnostics & Alerts
Pressurized Cab with Adjustable Vents
Joystick Pilot Controls – ISO Pattern
Rearview Mirror
Wide Entry Door & LED Interior Lighting
Dimensions & Weight
Length with Bucket: 147.8 in
Length without Bucket: 117.5 in
Width over Tracks: 77.2 in
Height to Top of Cab: 83.0 in
Operating Weight: 11,299 lbs
Ground Pressure: 4.7 psi
Buy with Confidence: we are so confident in the condition of our item that we offer a 10-day inspection policy and a 6-month warranty!
– Clean Title!
– Excellent Condition!
– Backed by our 6-month warranty!
– 10-Day Inspection Policy!
We also offer nationwide shipping at a competitive rate of $0.80 per mile. Our shipping service is handled with the utmost care, ensuring that your item arrives safely and in the same excellent condition in which it leaves our lot.
Whether you’re local or across the country, we’re committed to delivering the best online-buying experience possible. Reach out today and let us help you find your next item!
Contact us today for more information!!
Phone: +1 (314) 900-3911
